Heavy Duty Power Take Off PTO

JF7009

FAST Extra 8 gear .9 gear . 10 Gearbox part with ordinary auxiliary box with rear
window.like 8JS118,9JS119, RT11509C, RT-11609, 10JS120 etc

right-handed.700Nm Speed ratio:1.3
without disassembly

JF7009D

FAST 9 gear .10 gear the larger gearbox of the auxiliary box. like 9JSD150, RTD11509C,RTD11609, 10JSD140 etc

JF7012

FAST 12(16)gear and 10 Gear part with ordinary auxiliary box. like: 10JS160, 12JS180,16JS200 etc. (back cover 4The holes are not equally divided, M10 Threaded hole)

right-handed.700Nm Speed
ratio:1.41 without disassembly

JF7012D

FAST 12(16) gear and 10 Gear with enlarged auxiliary box. like 10JSD160,
12JSD180,16JSD200

JF7012DX

FAST 12(16) gear and 10 gear The new gearbox with enlarged auxiliary box.like:
10JSD160, 12JSD180,16JSD200

JF70C12

FAST 12(16) gear super transmission.like C12JSDQXL220T, C12JSDQXL240TA

right-handed.700Nm Speed ratio:1.3
without disassembly

JF70C12H

FAST 12(16) Gear super transmission with hydraulic retarder

JF7012DH

FAST 12(16) Gearbox with hydraulic retarder

right-handed .700Nm Speed
ratio:1.41 special model

JF70C2010

Qijiang 12TDS series. like:12TDS2210A

Left-handed .700Nm Speed ratio:1.0 Direct connection without disassembly

JF60D2010

Qijiang 12TDS series. like:12TDS2210A

right-handed .650Nm Speed
ratio:1.18 without disassembly

JF70-10TA

JIEFANG 10 gear, 12 gear torque less than or equal to 2100Nm the sum part
2300Nmof(output shaft spline 15 teeth) gearbox. like CA10TA130M, CA12TAX210M1,CA12TAX230M etc,

right-handed .700Nm Speed
ratio:1.30 without disassembly

JF70-10TAZ

JIEFANG 10 gear, 12 gear torque less than or equal to 2100Nm the sum part 2300Nmof(output shaft spline 15teeth) automatic transmission. like CA12TAX210A3Wait.Note:Common for pto and manual gear, with special cylinder for automatic gear

right-handed .700Nm Speed
ratio:1.30 without disassembly

JF70-12TA

JIEFANG 12 gear torque bigger than or equal to 2300Nm of (output shaft splines 19 teeth) gearbox. like CA12TA230M1, CA12TAX250M3, CA12TAX260M5 ETC,

right-handed.700Nm Speed ratio:
1.30 without disassembly

JF70-12TAZ

JIEFANG 12 gear torque bigger than or equal to 2300Nm of (output shaft splines 19 teeth) automatic transmission. like CA12TA230A3, CA12TAX250A3, CA12TAX260A5 etc,Note:Common for PTO and manual gear, with special cylinder for automatic gear

right-handed.700Nm Speed ratio:
1.30 without disassembly

JF70C9T160

JIEFANG 9 Gearbox. like:CA9T160M

Left-handed .700Nm Speed ratio:1.0 Direct connection without disassembly

JF60D9T160

JIEFANG 9 Gearbox. like:CA9T160M

Left-handed.700Nm Speed ratio:
1.18 without disassembly

HW70

Sinotruk 9-16 Gearbox ( Except 13710 and 90710 ) PTO connecting shaft length depends on the gearbox sequence number. General with hydraulic retarder 315MM Connecting shaft (the price of the pto with the extension shaft is slightly different)

right-handed.700Nm Speed ratio:
1.32 disassemble

HW70B

Same as HW70. The position of the pto drive plate is to the right 50MM

right-handed.700Nm Speed ratio:
1.32 disassemble

JF7013710

Zhangqiu Heavy Duty Truck 13710 gearbox

right-handed.700Nm Speed ratio:
1.41 without disassembly

JF70C1650

ZF16 Gear without hydraulic retarder, Valin Soda gearbox. like ZF16S1650,
ZF16S2530,12SOB1850,16SOK2250

Left-handed .700Nm Speed ratio:1.0
Direct connection without
disassembly

JF60D1650

ZF 16 gear, Valin Soda gearbox. like ZF16S1650, ZF16S2530, 12SOB1850, 16SOK2250

right-handed .600Nm Speed
ratio:1.18 without disassembly

JF650-1650

ZF16gear, Valin Soda gearbox. like ZF16S1650,ZF16S2530, 12SOB1850, 16SOK2250

right-handed.680Nm Speed ratio:
1.18 disassemble

JF70C2531

ZF16 Gearbox with hydraulic retarder. like 16S2231,16S2531

Left-handed.700Nm Speed ratio:
1.18 Direct connection without
disassembly

JF60D2531

ZF16Gearbox with hydraulic retarder. like 16S2231,16S2531

right-handed.600Nm Speed ratio:
1.18 ,without disassembly

JF650-2531

ZF16Gearbox with hydraulic retarder. like 16S2231,16S2531

right-handed.680NmSpeed ratio:
1.18 disassemble

JF70CDDMS

Hyundai Dymos gearbox. like T23OS12

right-handed.700Nm
Speed ratio: 1.0 Direct connection
without disassembly

JF60DDMS

Hyundai Dymos gearbox. like T23OS12

right-handed.600Nm Speed ratio:
1.18 without disassembly

JF60D2420

ZF12TX Series automatic transmission (including the transmission with hydraulic
retardation). like: 12TX2420TD

right-handed.600Nm Speed ratio:
1.18 without disassembly

JF70C1420

Dongfeng Tianlong 14 old style DT1420 gearbox.(The window is on the right side of the large drive shaft, and the hole spacing 80MMX80MM)

Left-handed.700Nm Speed ratio: 1.0 Direct connection without
disassembly

JF60D1420

Dongfeng Tianlong 14 old style DT1420 gearbox.(The window is on the right side of the large drive shaft, and the hole spacing 80MMX80MM)

right-handed.650Nm Speed ratio:
1.18 without disassembly

JF60D1422

Dongfeng Tianlong Volvo 14 Gearbox.(The window is under the large drive shaft) Such as: new DT1420,DT14,DT1422,DT1425,VT2514(old two-axis)

right-handed.650Nm Speed ratio:
1.18 without disassembly

JF70C1422

Dongfeng Tianlong Volvo 14 Gearbox.(The window is under the large drive shaft)Such as:new DT1420,DT14,DT1422,DT1425,VT2514 (The old model is directly connected to the left hand)

Left-handed.700NmSpeed ratio: 1.0 without disassembly

JF701422

Dongfeng Tianlong Volvo 14 Gearbox.(The window is under the large drive shaft) Such as:new DT1420,DT14,DT1422,DT1425,VT2514(three axes)

Left-handed.700Nm Speed ratio:
1.45 without disassembly

JF70D1422

Dongfeng Tianlong Volvo 14 Gearbox.(The window is under the large drive shaft)Such as: new DT1420,DT14,DT1422,DT1425,VT2514 (New version big two shafts)

right-handed.700Nm Speed ratio:
1.25 without disassembly

JF60D1422H

Dongfeng Tianlong Volvo 14Gearbox with hydraulic retarder. (old version two-shaft)

right-handed 650Nm
Speed ratio:1.18
without disassembly

JF701422H

Dongfeng Tianlong Volvo 14 Gearbox with hydraulic retarder. (three shaft)

Left-handed .700Nm Speed
ratio:1.45 without disassembly

JF70D1422H

Dongfeng Tianlong Volvo 14 Gearbox with hydraulic retarder. (New big two shafts)

right-handed.700Nm Speed ratio:
1.25 without disassembly

JF650-2541

ZF12AS Series with hydraulic retarder

right-handed.680Nm Speed ratio:
1.18 disassemble

JF650-2540

ZF12AS Series without hydraulic retarder

right-handed 680Nm Speed ratio:
1.18 disassemble

Note: The red color is marked as the old direct-connected left-hand rotation, with a small speed ratio. It is not recommended to install a new car. It is generally used for maintenance of the same model.
